Overview
Mitsubishi Electric High Voltage SiC MOSFET (HVMOSFET) modules provide inverter size reduction in traction motors, DC-power transmitters, and large industrial machinery.
Key Features
- Chip set combination is suitable for high-speed switching
- Reduced power loss compared to conventional HVIGBT
- Low inductance package for maximum SiC performance
Specifications
| Rated Voltage (Vces)/(Vds) | 3300 |
|---|---|
| Rated Current (Ices)/(Ids) | 200 |
| Viso (Vrms) | 6000 |
| Connection Type | Dual |
| Package Type | LV100 |
| Package/Dimensions (mm) | 100 × 140 |
