Overview

Power Modules for Electric Vehicle Propulsion

Key Features

  • Low Loss Mitsubishi Electric 7th generation CSTBT IGBT and RFC Diode technology
  • Direct cooling via integrated aluminum pin fin.
  • High reliability Direct Lead Bond structure.
  • Compact, lightweight, high power density.
  • Automotive qualified.

Specifications

Rated Voltage (Vces)/(Vds) 650
Rated Current (Ices)/(Ids) 700
Viso (Vrms) 2500
Connection Type 6-Pack
Package Type J1A
Package/Dimensions (mm) 115.7 x 120
RoHS Compliant Reach Compliant UL Compliant
