Mitsubishi Electric offers a wide power module lineup that contributes to energy savings and high reliability for industrial equipment. This T-Series device offers low power loss, improved reliability, and simplifies the inverter design process.

Key Features

  • Low Loss Mitsubishi Electric 7th generation CSTBT IGBT and RFC Diode technology.
  • Solid Cover (SLC) Package Technology eliminates a large solder layer, which contributes to improved reliability of industrial equipment.
  • New Industry Standard Pin Out and Footprint.


Rated Voltage (Vces)/(Vds) 1200
Rated Current (Ices)/(Ids) 800
Viso (Vrms) 4000
Connection Type Dual
Package Type LV100 Industrial
Package/Dimensions (mm) 100 x 140
