Overview
Mitsubishi Electric offers a wide power module lineup that contributes to energy savings and high reliability for industrial equipment. This T-Series device offers low power loss, improved reliability, and simplifies the inverter design process.
Key Features
- Low Loss Mitsubishi Electric 7th generation CSTBT™ IGBT and RFC Diode technology.
- Solid Cover (SLC) Package Technology eliminates a large solder layer, which contributes to improved reliability of industrial equipment.
- New Industry Standard Pin Out and Footprint.
Specifications
| Rated Voltage (Vces)/(Vds) | 1200 |
|---|---|
| Rated Current (Ices)/(Ids) | 1200 |
| Viso (Vrms) | 4000 |
| Connection Type | Dual |
| Package Type | LV100 Industrial |
| Package/Dimensions (mm) | 100 x 140 |
